By Syed Fazle Rahman

Bootstrap is undoubtedly one of the most popular front-end frameworks. With more than 73k stars and 27k forks, Bootstrap is also one of the most popular GitHub repositories. In my last article, Responsive Web Design Tips from Bootstrap’s CSS, I explained how Bootstrap functions as a responsive framework. In this article, we will discuss a related topic: The Grid System, one of the most important concepts in Bootstrap.

What is the Bootstrap Grid System?

Like any grid system, the Bootstrap grid is a library of HTML/CSS components that allow you to structure a website and place a website’s content in desired locations easily.

Think of graph paper, where every page has a set of vertical and horizontal lines. When these lines intersect, we get squares or rectangular spaces.

Graph paper

By Sfoerster (Own work) CC-BY-SA-3.0, via Wikimedia Commons

Well, this is also true for Bootstrap’s Grid System. It allows you to create rows and columns and then place content in the “intersected” areas.

Now the question is, how many rows and columns you can create using Bootstrap’s Grid System? Bootstrap allows you to create up to 12 columns and unlimited rows — hence the name 12-Grid System. So, let’s see how we can utilize this grid system to create various types of layouts.

Getting started with Bootstrap’s Grid System

To get started, naturally, you’ll need to have the necessary assets in your page to get Bootstrap working. If you’re new to Bootstrap, you can refer to our previous article Getting started with Bootstrap or my book Jump Start Bootstrap, to dig deeper.

Bootstrap’s Grid System is made up of 3 things:

1. A container

2. Rows

3. Columns

Let’s explore each of the above in detail.

Creating a Container

Bootstrap’s grid system needs a container to hold rows and columns. A container is a simple <div> element with a class of .container. The container is used to provide a proper width for the layout, acting as a wrapper for the content. Here is the code for this task:

<div class="container">
  Some content
</div>

Here the container element wraps the content and sets left and right margins. It also has different fixed widths in different sized devices. Have a look at the following table:

Device Width	Container Width
1200px or higher	1170px
992px to 1199px	970px
768px to 991px	750px
Less than 768px	auto

You can choose a fluid container if you are not fond of a fixed layout. To do this, you use the class .container-fluid. A fluid container has no fixed width; its width will always be the width of the device.

Just note that both fixed and fluid containers have padding of 15px on the left and right sides.

Creating a Row

A row acts like a wrapper around the columns. The row nullifies the padding set by the container element by using a negative margin value of -15px on both the left and right sides.

A row spans from the left edge to the right edge of the container element. It is created by adding the class .row to a block level element inside the container.

Have a look at the following CodePen:

<div class="container">
  <div class="row">
    Some content
  </div>
</div>

In this demo, you can see the text touching the left edge of the container element. This is because the container’s padding has been removed by the row due to the negative margins on the row.

Finally, there’s no limit on the number of rows you can create.

Creating Columns

Bootstrap uses different column class prefixes for different sized devices. These prefixes are shown in the table below:

Class Prefix	Device Size
.col-xs-	< 768px
.col-sm-	768px to 991px
.col-md-	992px to 1199px
.col-lg-	≥ 1200px

So, let’s create our first Bootstrap column:

<div class="container">
  <div class="row">
    <div class="col-xs-12">
      Some content
    </div>
  </div>
</div>

In the above demo, I used the class .col-xs-12 to create a single column that spans across 12 virtual Bootstrap columns. Hence, this column’s width will be the width of the row.

In the above demo, you will also see the 15px padding reappear to push the element away from the container. This is because every column in Bootstrap has a padding of 15px.

You must be wondering why I used the class prefix that belonged to extra smaller devices, which is .col-xs-. In Bootstrap, if a column is defined for a particular type of device then it is guaranteed to behave similarly in larger devices as well. Therefore, a column defined for extra smaller devices will work in all types of devices.

Let’s now create a 2-column layout for smaller devices and check out its behaviour in larger devices and extra-small devices. We will use the class prefix .col-sm- here. To create 2 columns of equal widths, we should assign 6 virtual Bootstrap columns to each one of them. This way, we maintain the limit of 12 virtual Bootstrap columns for a single row.

<div class="container">
  <div class="row">
    <div class="col-sm-6">
      <h1>Bootstrap Grid Demo</h1>
    </div>
    <div class="col-sm-6 other">
      <h1>2 Columns</h1>
    </div>
  </div>
</div>

Nesting with the Grid System

Nesting is one of the ways to create complex designs using Bootstrap’s grid system. It is also the one section where many first-timers have trouble.

We understand that to use Bootstrap’s grid system, we need 3 things: A container, rows, and columns. So to nest a grid system within a column we will need the same three things. But the only difference is that the container is already defined. In this case, the columns will behave as the containers for the nested grid system.

Here’s the logic: The containers provide 15px of padding, which is nullified by the row. Then we define columns that again have 15px of padding on the left and right side. So, to nest a grid system within a column, we simply need rows and columns. No .container or .container-fluid elements are necessary for a nested grid system.

Here’s an example of a nested grid system:

Bootstrap grid demo with nested columns

What About More than 12 Columns?

This is one of the root causes for disordered Bootstrap layouts. A wrong calculation in deciding the number of virtual Bootstrap columns can lead to an improper layout.

In such a case, a virtual row will be created and unfitted columns will shift to the next row. For example, if you have defined 2 columns with the classes .col-md-8 and .col-md-5, the second column will shift to a new row because it requires 5 virtual Bootstrap columns whereas only 4 are left.

Helper Classes

Bootstrap provides various helper classes that can be useful in certain situations in dealing with grids. These classes are:

• .clearfix: Normally used to clear floats, adding this class to any column will make it shift to a new row automatically, to help you correct problems that occur with uneven column heights.

• Offsetting columns: You don’t have to occupy all 12 of the virtual columns. You can use offset classes like .col-xs-offset-* or .col-md-offset-* to leave a particular number of virtual Bootstrap columns to the left of any column (kind of like invisible place holders).

• Reordering: Use classes like .col-md-push-* and .col-md-pull-* to shift a column to the right or left, respectively.
